Geode

Know when it passes.
From anywhere.

One compact AGM. Three ways to deploy. Four synchronized signals with live fleet visibility and precise passage data.

Request a demoExplore Geode

Built by pipeline professionals in Oklahoma

Portable Geode on small feet, with a charcoal body, orange lid, fixed carry handle, OLED, and one green status light
One Geode. Three configurations.
Portable · Ground spike · Pipeline mount
4Synchronized signals
≤100 msClock accuracy
LTE-MCloud connected
3Deployment options

Three ways to deploy

Same Geode.
Your choice of placement.

From a temporary survey point to a permanent position on the line.

Portable Geode resting on small black feet with a fixed full-width carry handle and orange lid

01Set it down

Portable with feet

Carry Geode to the next location and set it on its four small feet. A compact setup for moving between survey points.

Four feet · Fixed carry handle

Geode with one removable metal spike extending from the center of its underside, with the full pointed tip visible

02Place it in the ground

Removable ground spike

Add a single center-mounted metal spike for ground deployment. Remove the spike when your next location calls for the portable setup.

Center-mounted · Removable spike

Geode mounted directly on a horizontal pipeline using a compact stainless saddle and two bands around the pipe

03Keep it on the line

Permanent pipeline mount

Position Geode directly on a horizontal pipeline. A compact stainless saddle and two bands form the permanent mounting option.

Direct to pipe · Saddle and two bands

One familiar enclosure.

A textured charcoal body, solid orange lid, and fixed full-width handle across all three configurations.

Explore the specifications
Compact body
Approx. 160 × 90 × 60 mm (L × D × H), excluding handle, feet, and mounting hardware.
Status at a glance
A thin 0.91-inch OLED, one green status LED, and a separate circular power button.
Covered connections
USB-C with a matching oblong tethered cover on the left; a round capped service connector on the right.
Easy to carry
A fixed handle spans the full width and sits centered over the lid.
A closer look at GeodeExplore all six sides of the portable enclosure.
Six views of the portable Geode: orange lid and centered fixed handle from above; four feet underneath; left USB-C with oblong tethered cover; right round capped service connector; front OLED, power button, one green LED and branding; plain charcoal back
Portable enclosure · Select the image to open it at full size.

Why Geode

Modern tracking without the usual tradeoffs.

Check locally. Monitor remotely. Keep one synchronized passage record.

01

No field app required

Check battery, GPS, LTE, and sensors from any phone browser.

02

Four signals, one timeline

See ELF, acoustic, magnetic, and vibration data together.

03

Power managed remotely

Manage operating modes and check battery status from wherever you are.

Multi-sensor detection

One device.
Four ways to know.

Four signals help separate a real passage from noise.

ELF transmitter

Detects 15–35 Hz transmitter pulses.

Geophone

Captures the acoustic passage signature.

Magnetometer

Maps the magnetic signature to a precise timestamp.

MEMS accelerometer

Adds independent vibration confirmation.

Field workflow

From placement to passage.

Choose your setup. Check locally. Follow the run remotely.

1

Position it

Choose portable feet, a removable ground spike, or a permanent pipeline mount.

2

Check it

Confirm battery, location, network, and sensors.

3

Set it

Choose the operating mode for your run.

4

Track it

View live data and passage alerts.

Scissortail Companion showing live MAG, ELF Coil, GEO, and ACC signals from a connected Geode

Scissortail Companion

Every signal.
One clear view.

Connect to a nearby Geode and inspect synchronized live signals, device health, saved events, and recorded history.

  • Live MAG, ELF Coil, GEO, and ACC traces
  • Saved events and recorded history
  • Battery, Bluetooth, LTE, and device health
  • Available on desktop, iOS, and Android

Scissortail Companion

Your field data.
Wherever you work.

Open Companion in your browser, or download the latest desktop and mobile releases below.

Open Companion web app
Checking the latest desktop release…

Mobile apps

Built for the field.

Scissortail Companion is available on the App Store for iPhone and iPad, and version 0.8.4 is on Google Play in the United States. Android users can also download the latest APK or join the public Google Play test.

Checking for mobile releases.

Previous releasesFind installers and verification files from earlier stable releases.Checking…

Desktop

Checking the desktop release archive…

Geode’s local web interface remains available without installing an app.

Product details

Geode specifications.

A compact enclosure with three deployment options.

Detection
ELF coil, geophone, 3-axis magnetometer, MEMS accelerometer
Connectivity
LTE-M, WiFi access point, GNSS
Timekeeping
NTP-synchronized real-time clock, ≤100 ms accuracy
Power
Rechargeable Li-ion battery
Operating modes
Sentinel, standby, stream, and deep sleep
Configurations
Portable with four feet; removable center ground spike; permanent direct pipeline mount
Enclosure
Textured charcoal body, solid orange lid, fixed full-width handle
Body dimensions
Approximately 160 mm long × 90 mm deep × 60 mm high; excludes handle, feet, and mounting hardware
Protection target
IP67 design target; not a certified rating
Display & controls
0.91-inch OLED, one green status LED, separate circular power button
Connections
Left-side USB-C with matching oblong tethered cover; right-side round capped service connector
Pipeline mounting
Compact stainless saddle with two bands around a horizontal pipeline
Local access
Built-in mobile web interface; no app required
Cloud access
Live fleet status, waveform review, remote control, and reporting
Companion apps
Available for desktop, on the App Store and TestFlight for iOS, and on Google Play in the United States for Android

See Geode in the field

Bring live visibility to your next pig run.

See Geode work with real field data.

Request a Geode demo
